Detail produk:
|
Tegangan nominal: | 380V, 400V , 415V | Listrik nominal: | 180A/360A |
---|---|---|---|
Kecepatan: | 1500RPM | Frekuensi: | 50HZ, 60HZ |
Sistem awal: | Start Otomatis, start jarak jauh, Start Listrik 12V DC, Start Listrik 24V DC | Berat badan: | 2680X1100X1732MM /1120KGS |
sertifikat: | CE/ISO14001 | Alternator: | Leroy Somer |
Keluaran alternator: | 20-2000kva | Warna: | Permintaan Pelanggan |
Modul Pengontrol/Kontrol: | Smartgen | Mesin: | dengan Ricardo yuchai/weichai/perkins dll. |
Pilihan: | Sakelar Transfer Otomatis | Metode Pendinginan: | Air didinginkan |
Jenis: | generator diesel tipe kontainer 100kw | Fase: | 3 Fase 4 Kawat |
Jaminan: | 12 bulan/1000 jam |
Specification: | ||||||||
GENERATOR SET | ||||||||
Genset model | KGC20-2000S | |||||||
Prime powe (KW/KVA) | 20-2000KW | |||||||
Standby power (KW/KVA) | 22-2200KW | |||||||
Frequency & Voltage | 400V/50Hz | |||||||
Number of Phase | 3 | |||||||
Genset type | container type | |||||||
Reference Dimension & Weight | 5800x2330x2360mm & 5010kgs | |||||||
DIESEL ENGINE | ||||||||
Engine brand & Model | Kingway & KAI2200 | |||||||
Rated output | 20-2000kw | |||||||
Rated speed | 1500RPM | |||||||
Engine Type | In-line, direct injection, four stroke | |||||||
Aspiration method | Turbocharged intercooled | |||||||
Governor | Mechanical/Electrical | |||||||
Starting method | Electric starting | |||||||
Cooling method | Forced water cooled | |||||||
Displacement | 6L | |||||||
Fuel consumption | 205g/kw.h | |||||||
Rotation direction of crankshaft | Counter clockwise(face to flywheel end) | |||||||
ALTERNATOR | ||||||||
Alternator brand & Model | Stamford/Leroy Somer/China reputed brand | |||||||
Type | Brushless & self-excited | |||||||
Number of phase | 3 | |||||||
Voltage | 400V | |||||||
Frequency | 50Hz | |||||||
Power Factor | 0.8 | |||||||
Insulation Grade | H | |||||||
Protection Grade | IP22/23 | |||||||
Altitude | ≤1000m |
